kode komandi

Mɔdɛli	4V310-08 4V320-08	4V330C-08 4V330E-08 4V330P-08	4V310-10 4V320-10	4V330C-10 4V330E-10 4V330P-10
Ji	Fiɲɛ (ka filtɛri kɛ ni 40μm filɛrifɛn ye)
wale	Kɔnɔna kurun kɔnɔ walima pilɔti kɛnɛma .
Port size[Note1]	=Out=Sɛbɛn{{2}/4"		=Out=3/8"Sɛbɛn=1/4"
A bonya	25.0mm2 (Cv=1.40)	18.0mm2 (Cv=1.00)	30,0mm2 (Cv=1.68)	18.0mm2 (Cv=1.00)
Valve sugu	5 port 2 lɔyɔrɔ	5 port 3 lɔyɔrɔ	5 port 2 lɔyɔrɔ	5 port 3 lɔyɔrɔ
ka degun baara	0.15~0.8MPa(21~114pssi)
ka degun	1.2MPa(175psi)
Gwanniyahakɛ	-20~70 degere
Farikoloɲanagwɛko	Aliminiyɔmu nɛgɛ
Lubrucation[Note2]	A man kan
Max.frequency [Note3]	4 yɛlɛmani/seki	3 cycle/sec	4 yɛlɛmani/seki	3 cycle/sec
Giri (g)	4V310-08:310 4V320-08:400	450	4V310-10:310 4V320-10:400	450

Tagamasiɲɛw:

1.Pilot-}olisited cogoya: kɔnɔna pilɔti walima pilɔti kɛnɛma.

2.Labɛnnin be kolon yɛlɛmani na: a ka ɲi ani a be se ka yɛlɛma .

3.Solenoid valve saba be ni yɔrɔ saba ye minw be se ka kɛ i ka sugandili ye.

4.Solenoid vanne minw be se ka yɛlɛma, olu be ni hakilijagabɔ baara ye .

5.Nafolo dingɛ be baarakɛcogo kɛrɛnkɛrɛnnin dɔ ta min tɛ ni yɛlɛmani ye min tɛ se ka yɛlɛma, a be daminɛ ni fanga ye ani a be se ka baara kɛ a ka baara la.

6. Kuun t’a la ka tulu fara tulu kan.

7.lt be sɔrɔ ka se ka valve kulu don ɲɔgɔn na ni baseto ye min be sigi yɔrɔ min na, o yɔrɔ mara.

8.Baalo minɛn minw be ɲɔgɔn sɔrɔ, u be minanw labɛn walisa ka nɔgɔya ani ka debugging nɔgɔya.

9. tanuli hakɛ min be sɔrɔ, o tɛ se ka kɛ.
